Security Paper

Deliver flawless security paper that meets your customers’ high standards.

The inspection solutions in our BankSTAR product family give you continuous paper monitoring throughout the entire production process. They inspect the substrate for defects and ensure that all security elements are defect-free. By detecting defects as early as possible within ongoing processes, the systems prevent defective material from further processing, making production more efficient.

Discover our solutions - Paper Machine Wet Section

Paper Machine Wet Section

Paper Machine Dry End

Production Analytics

Service & Training

Paper Machine Wet Section

BankSTAR PM – WS is ISRA SURFACE VISION’s answer to the particular challenges of optical inspection in the wet section of the paper machine. The system is engineered for operation in the typical rough-and-tough environment of a paper mill, with its usually high levels of humidity and dust. BankSTAR PM – WS is especially designed for the inspection and measurement of all kinds of security threads - including window threads with varying window sizes, flip thread detection and thread elongation assessment -, as well as the detection of dirt, foreign objects and other paper defects that can be optically detected as early as when the pulp is collected by the sieve in the wet section of the paper machine.

Furthermore BankSTAR PM – WS provides precise web and sub-web measurements, thus enabling process parameter optimization with measurement values retrieved from this very early stage of the production process.

Benefits

Features, typical defects and technical data

Features

High-speed, high-resolution line-scan cameras
Ultra-bright illumination modules
Inspection using visible, ultraviolet or infrared light
Real-time processing

Typical defects

Substrate defects like pinholes, inclusions, spots, streaks
Design/décor defects like missing bits, positioning defects, print defects

Technical data

Paper weight 45 - 160 g/m2
Speed up to 360 m/min
Width between 400 mm and 1000 mm
Sheets length up to 1000 mm

Download additional information

Discover our solutions - Paper Machine Dry End

Paper Machine Wet Section

Paper Machine Dry End

Production Analytics

Service & Training

Paper Machine Dry End

Thin places security

BankSTAR PM is installed at the dry end of the paper machine and detects the overwhelming majority of critical paper defects before slitting and cutting of the substrate. Inspecting the substrate at this point in the production chain is of paramount importance for production efficiency and quality assurance.

BankSTAR PM’s inspection channel in transmission checks all types of watermarks, e.g., artisanal registered/localized high-resolution watermarks, edge-/cornerstone watermarks, e-types, skew marks and cutting marks, and measures sheet length, width and geometry.

A specific combination of additional inspection channels in reflection enables BankSTAR PM to also detect dirt, inclusions, thin areas and other typical paper defects, as well as ‒ depending on the configuration ‒ low-contrast defects, e.g., wrinkles (double and triple substrate) and streaks, thereby allowing the machine operator to adjust production parameters and eliminate imperfections while they happen. By the same token BankSTAR PM helps the paper mill avoid further processing of defective material.

Benefits

Exact data on paper geometry

Precise information on paper
quality and capacity of good
production

Avoid adding value to
defective material

Easy identification with ink
marking unit

Features, typical defects and technical data

Features

High-speed, high-resolution line-scan cameras
Ultra-bright illumination modules
Inspection using visible, ultraviolet or infrared light
Real-time processing

Typical defects

Substrate defects – pinholes, inclusions, spots, streaks,….
Design/décor defects – missing bits, positioning defects, print defects,….

Technical data

Paper weight 45 - 160 g/m2
Speed up to 360 m/min
Width between 400 mm and 1000 mm
Sheets length up to 1000 mm

Download additional information

Discover our solutions - Finishing

Paper Machine Wet Section

Paper Machine Dry End

Production Analytics

Service & Training

Finishing

BankSTAR OV is specifically engineered for the assessment of the integrity and quality of objects and features applied in the converting steps of the security paper production process. The “OV” configuration of BankSTAR performs high-precision inspection tasks in the converting or “OV” line ‒ otherwise known as ”finishing line” or ”application line” ‒, with special focus on the application of holographic objects, iridescent print, primer print and backside foils.

BankSTAR OV is capable of performing extremely complex measurement and inspection tasks, such as checking secure window features with transparent or opaque holograms, where the hole punching, the backside foil and the centered positioning of the hologram feature within the window, as well as its integrity, must be verified.

Benefits

Features, typical defects and technical data

Features

High-speed, high-resolution line-scan cameras
Ultra-bright illumination modules
Inspection using visible, ultraviolet or infrared light
Real-time processing

Typical defects

Substrate defects – pinholes, inclusions, spots, streaks,….
Design/décor defects – missing bits, positioning defects, print defects,….

Technical data

Paper weight 45 - 160 g/m2
Speed up to 360 m/min
Width between 400 mm and 1000 mm
Sheets length up to 1000 mm

Download additional information

Discover our solutions - Cross-Cutter

Paper Machine Wet Section

Paper Machine Dry End

Production Analytics

Service & Training

Cross-Cutter

BankSTAR CC is the most versatile and complete of all BankSTAR configurations. Housed in its own vibration-absorbing frame with high-precision rollers in front of the knife at the cross-cutter or sheeter, BankSTAR CC can inspect virtually any feature and detect virtually any defect type in security paper: dirt/spots, thin areas, wrinkles, security threads, holographic features, iridescent printing, etc.

The job of BankSTAR CC is final quality assurance and allocation of sheets to the good, doubtful and bad piles by sending the corresponding output signals to the cross-cutter. Hence, BankSTAR CC enables security paper mills to deliver 100% inspected quality to their customers.

BankSTAR CC has a fail-safe mechanism ensuring that no defective sheets are sent to the bad pile. All sheets are first classified as bad sheets. If a defect is found, this classification is upheld and the sheet is sent to the bad pile. The same happens if there is any technical problem. Only if a sheet is properly processed and no defect is found, that sheet is re-classified as a good sheet and sent to the good pile.

BankSTAR CC interfaces perfectly – both mechanically and logically – with the security paper cross-cutters of all major manufacturers.

Benefits

Features, typical defects and technical data

Features

High-speed, high-resolution line-scan cameras
Ultra-bright illumination modules
Inspection using visible, ultraviolet or infrared light
Real-time processing

Typical defects

Cutting/slitting defects

Technical data

Paper weight 45 - 160 g/m2
Speed up to 360 m/min
Width between 400 mm and 1000 mm
Sheets length up to 1000 mm

Download additional information

Discover our solutions - Production Analytics

Paper Machine Wet Section

Paper Machine Dry End

Production Analytics

Service & Training

Production analytics - Data-driven production efficiency

The web-based production analytics platform allows you to check the system status of all production lines at a glance or analyze production data in detail. With the quality management system, you analyze historical data, monitor current inspection data in real-time, and identify future trends in your production process.

Optimization of production

Dashboards allow you to compare production line and product data onsite or remotely, providing key insights for optimization. This enables you to make informed professional decisions along your value chain to increase the product quality as well as profitability. You can continuously track the progress of optimization measures and present them with visualized advanced reports.

Early detection of production defects

Detect and quickly identify the cause of threshold value violations at every stage of production with live status information and automatic alerts. As a result you can quickly resolve production defects, shorten downtime, and reduce production costs.

Predictive maintenance

You can prevent potential system failures by analyzing real-time data from the sensors and monitoring systems. This allows proactive planning of maintenance, based on the actual condition of the machines, instead of following a fixed schedule. This data-driven approach saves costs through reduced downtime and increased overall productivity, as well as longer production line life.

Your benefits

Time-saving multi-line overviews, one view for all quality-related information
Minimize downtime by monitoring system health data
Faster reaction to quality issues with quality data monitoring
Fast elimination of production defects, reduction of production costs
Improved maintenance for reduced downtime, higher overall productivity and longer production line life

Key features

Overview on production data and plant status

Web-based solution, no client software installation required

Department oriented dashboards, customer specific adaptations are possible

Live insights from real time data

Threshold monitoring and alerting

Open to integrate relevant third-party data and export data to the customer's systems

Discover our solutions - Service & Training

Paper Machine Wet Section

Paper Machine Dry End

Production Analytics

Service & Training

Customer service & training

For the efficient and future-proof operation of your production systems our highly qualified service teams support you globally in all matters. We provide the implementation, maintenance and servicing as well as the analysis and optimization of your systems - quickly, reliably, 24/7.

Visit our service center and request your customized service solution.

Furthermore, learn in the ISRA VISION Academy how our competent trainers always keep your employees up to date with the latest knowledge so that system operators, product engineers and quality managers become real inspection experts.

Visit our ISRA VISION Academy and book your individual and scalable trainings.
