Inspection solutions for solar modules

Increased output: Achieve maximum yield with fully exploited production potential

Saved resources: Optimum use of material, equipment, and engineering times

Maximum process transparency: Anticipate process weaknesses at the earliest possible

Modules

Reduce your production costs and make sure that the modules you produce are of outstanding quality.

To achieve this outstanding quality, the raw materials have to be right. Our inspection solutions for incoming cells, thin film, foil, or solar glass detect the smallest defects and faulty material. Subsequent removal saves valuable production capacity.

Cloud-based data management reduces set-up workload and significantly accelerates commissioning and recipe adjustments.

Our modules solutions are powered by our brand:

Discover our solutions - Incoming cell inspection & classification

Incoming cell inspection & classification

PL String Inspection

Data Analytics / CPV

Service & Training

Incoming cell inspection & classification

Identifying faulty cells before the stringer saves valuable module production capacity. CELL-Q identifies faulty cells in time and monitors their performance class. Damage caused by transporting and handling can be claimed and rectified.

Benefits

Features, typical defects and technical data

Features

Incoming cell control before stringer
Contact Grid inspection: detection of print defects and monitoring of printing position
Color sorting: detection of color and coating defects and cell sorting by color classes
Detection of other surface and contour defects
Simple recipe exchange / Recipe Copy-Exact

Typical defects

Color defects: discolorations, inhomogeneities
Surface defects: stains, fingerprints, scratches
Grid defects: interruptions, thinnings, slubs, nodes, stains, smearings, mispositioning

Technical data

Even for wafer sizes over 210 mm
Recipe Copy-Exact
LightDome Technology for the highest isotropy and homogeneity
Multiview Technology for the highest sensitivity in surface defect detection
Image analysis on cumulative defect overlay image
Matrix camera technology for best metrology

Download additional information

CELL-Q flyer en 247.8 kB, PDF
CELL-Q flyer cn 474.2 kB, PDF

Discover our solutions - PL String Inspection

Incoming cell inspection & classification

PL String Inspection

Data Analytics / CPV

Service & Training

PL String Inspection

Strings are the backbone of solar modules, and ensuring their quality is paramount. Photoluminescence (PL) inspection for the stringer ensures that only high-quality strings make it into the final assembly.

This cutting-edge technique employs the power of light to uncover imperfections and elevate the quality of photovoltaic strings.

At its core, PL inspection involves illuminating the cells with specific wavelengths of light, stimulating the emission of photons. This emitted light, when carefully analyzed, provides critical information about the string's material integrity and electrical characteristics. ISRA VISION’s PL inspection system LUMI-Q Scan runs laser-free, which reduces safety requirements.

This cutting-edge technique employs the power of light to uncover imperfections and elevate the quality of photovoltaic strings.

Benefits

Reduced operational costs through minimized rework

Increased process yield and uptime

Optimized module efficiency and stability

Easy integration and fast ramp up

Features, typical defects and technical data

Features

Detection of all relevant defects on solar strings directly in stringer
Laser-free and contactless inspection technology
Seamless integration without additional footprint (retrofit-ready)
Optional: Fab data management with central recipe management and comprehensive data reporting

Typical defects

Electrical & material defects: Microcracks, soldering defects, insulated areas, scratches, stains, electrical cell mismatch
Geometrical defects: ribbon misalignment, ribbon kink/cell shifting, string properties/geometry

Technical data

On-the-fly measurement
Fast measurement speed:
- ≥ 800 mm/s @ 3k
- ≥1200 mm/s @ 1k
Even for wafer sizes >210 mm

Download additional information

LUMI-Q-STRING brochure 2.1 MB, PDF

Discover our solutions - Data Analytics / CPV

Incoming cell inspection & classification

PL String Inspection

Data Analytics / CPV

Service & Training

Data Analytics / CPV

Transparency increases efficiency: Visualize and analyze process data in real-time. All our inspection systems provide data for yield evaluation and comparison to anticipate and counteract process deviations.
